KOBELCO SK500XDLC

Designed for the most extreme work environments, the SK500XDLC is purpose-built with a robust machine body and substantial additional reinforcements to all key areas of stress and wear across the boom, arm, underbody and undercarriage.

Experience next-level lifting capabilities with the standard extreme duty 7.0m boom and 3.45m arm, reaching a 7.81m dig depth with a rated safe working load over 6,000 kg (measured at full reach over the side). For even greater capacity, the XD Series is also available in a mass excavation (ME) configuration, known as the SK520XDLC. Equipped with additional counterweight and a shorter 6.5m boom and 2.6m arm, the SK520XDLC delivers even higher breakout forces and additional bucket capacity, with a rated safe working load exceeding 8,000 kg.

Features

• Includes Kobelco’s Extended Major Component Warranty of 4 years/6,000 hours!
• Kobelco’s GEOSCAN telematics system is also provided free of charge for 5 years, allowing remote access to a comprehensive set of machine operational and maintenance data from any web enabled device.

Specifications

• Length, Width & Height: 12.23 x 3.58 x 3.38 m
• Operating Weight: 52,200 kg
• Max. Digging Depth: 7.81 m
• Max. Digging Reach: 12.04 m
• Bucket Digging Force: 293 kN (ISO 6015)
• Arm Crowding Force: 222 kN (ISO 6015)
• Fuel Tank: 638 L
• Hydraulic Oil Tank: 371 (631) L
• Rated Power Output: 257 kW
• Rated Torque: 1,400 Nm
• Max. Pump Flow: 2 x 370 L/min + 60 L/min
• Standard Auxiliary: N&B + Tilt Piping
