Kobelco has taken the next evolutionary step by packing even more digging power and practical performance features into the SK45SRX while maintaining a short tail swing. The new Energy Conservation Mode saves even more fuel, and Kobelco’s proprietary iNDr Cooling System ensures quiet operation, protection from dust, and easy maintenance.
This model also adopts a square ROPS cab or canopy complete with wide foot space, and added windows for a clear vision of the worksite. The high-strength canopy meets ROPS and FOPS standards for greater operator safety. For greater operator comfort and safety, the rectangular cab design offers plenty of room and an unobstructed view. It all adds up to enhanced full-size performance, short-radius agility and a low-noise environment, with exceptional performance features and a full range of value-added functions
The iNDr system on the SK45SRX features air intake at the front of the machine and air exhaust underneath. It functions in the same way as the iNDr System on the SR series machines. The stainless-steel filter is extremely effective against dust, with 30-mesh wave-type screen that removes tiny dust particles from the intake air and delivers amazingly quiet operation. The highly airtight engine compartment and the offset duct contribute to noise reduction.
The SK45SRX/SK55SRX features one-touch deceleration, allowing easy switching to an idling state, reducing the fuel consumption while the machine is at rest.
Features
- Reliable construction
- Fast and powerful digging and levelling
- A short tail swing allows operators to work in tight spaces
- Standard 4 year/4,000 hour Full Machine Warranty.
- High-strength canopy that meets ROPS and FOPS standards
Specifications
- Length, Width & Height: 5.32 x 1.96 x 2.53 m
- Operating Weight: 4,660 kg
- Max. Digging Depth: 3.44 m
- Max. Digging Reach: 5.9 m
- Bucket Digging Force: 35.2 kN
- Arm Crowding Force: 20.9 kN
- Fuel Tank: 75 L
- Hydraulic Oil Tank: 27.9 (57.7) L
- Rated Power Output: 29.1 kW
- Rated Torque: 139.1 Nm
- Max. Pump Flow: 2 x 49.9 + 33.8 + 10.8 L/min
- Standard Auxiliary: N&B + Tilt Piping
