KOBELCO SK210LC-10 High and Wide

The Kobelco SK210LC High and Wide excavator is part of the Kobelco line-up of specially equipped machines for forestry and hilly terrain work.

The high and wide specification series has generous ground clearance and the extra crawler width ensures excellent stability for greater lifting capacity.

Durability is significantly improved with full track guides and larger upper rollers for the crawlers which prevents de-tracking. The double grouser shoes provide better grip and are designed to work smoothly over the roughest ground.

Features

• Specially equipped machines for forestry and hilly terrain work
• Comes with 2YR/3,000HR Full Machine Warranty and 4YR/6,000HR Major Component Extended Warranty.

Specifications

• Length, Width & Height: 9.45 x 3.24 x 3.37 m
• Operating Weight: 25,100 kg
• Max. Digging Depth: 6.36 m
• Max. Digging Reach: 9.9 m
• Bucket Digging Force: 157 kN
• Arm Crowding Force: 112 kN
• Fuel Tank: 320 L
• Hydraulic Oil Tank: 140 (244) L
• Rated Power Output: 118 kW
• Rated Torque: 592 Nm
• Max. Pump Flow: 2 x 220 + 20 L/min
• Standard Auxiliary: N&B + Tilt Piping
