KOBELCO ED160BR-7 Blade Runner

The ED160BR Blade Runner has the power to doze and backfill in all recommended operating positions. With unforgettable comfort with a Grammer air suspension seat as standard and a 10-inch colour monitor. Excellent ground clearance ensures unhindered travel.

Includes Kobelco Geoscan Excavator Remote Monitoring System.

Features

• Excavator and dozer in one versatile machine.
• Tier 4 Final compliant engine.
• 6-way power angle-tilt blade with single-level dozer control.
• 2YR/3,000HR Full Machine Warranty and 4YR/6,000HR Major Component Extended Warranty.

Specifications

• Length, Width & Height: 8.55 x 2.59 x 2.82 m** (**600 mm shoe)
• Operating Weight: 17,000 kg with dozer
• Max. Digging Depth: 5.36 m
• Max. Digging Reach: 8.17 m
• Bucket Digging Force: 105.4 kN
• Arm Crowding Force: 64.0 kN
• Fuel Tank: 186 L
• Hydraulic Oil Tank: 89.9 (190) L
• Rated Power Output: 86.0 kW
• Rated Torque: 375 Nm
• Max. Pump Flow: 2 x 142 L/min + 22, 67 L/min
• Standard Auxiliary: N&B + Tilt Piping
